Overview
Built for the booth.
The 1 US Gallon Raptor Kit is the industry standard in bedliner coating. Each kit contains four bottles of Raptor and one tin of hardener. Each kit covers approximately 125 square feet, enough to do a full size pick-up truck bed. Compatible with both Raptor Schutz and Professional Vari-Nozzle application guns.
U-POL RAPTOR UP0821V is a low-VOC, tintable coating kit formulated for automotive refinishing and collision repair. Designed for a 3:1 mix ratio, the system provides a uniform finish on a wide range of substrates, including aluminum, bare metal, e-coat, fiberglass, galvanized steel, plastics, polyester, wood, and concrete.
With a VOC content of 9.18 lb/gal (1120 g/L), the kit delivers up to 125 sq ft coverage per kit at two coats. The coating flashes off in approximately 60 minutes, allowing additional layers without compromising adhesion. Its fast cure and high solids content make it suitable for high-throughput body shops seeking consistent color matching and durability.
Due to the listed GHS hazards-acute toxicity, skin corrosion, eye damage, flammability, and respiratory risks-use of appropriate personal protective equipment is mandatory: safety glasses or goggles, chemical-resistant gloves, protective clothing, and a respirator. Ensure adequate ventilation during mixing and application.
Why Pros Choose U-POL 2.6 VOC
- Provides a tough scratch and stain resistant surface and protects against rust and corrosion
- UV resistant - delivers a high level of fade resistance
- Water resistant - provides a water resistant finish, keeping moisture out and reducing rust
- Resistant to a wide range of chemicals including fuels, hydraulic oils, animal urine, salt water and more
- Quick and easy to use
- Easy as fill-shake-shoot
- Provides excellent adhesion across many substrates
- Easy to clean simply hose off
- Can be applied with U-POL® application gun, HVLP gun, roller or brush
- Tintable - Customizable to match any color
How to Use
Use for automotive, construction, marine, recreational, industrial, agricultural and commercial applications.
- Clean and degrease the substrate (aluminum, bare metal, concrete, e-coat, fiberglass, galvanized, OEM plastic, polyester, primer, SMC, wood) to remove all oils, rust, and loose material.
- Mix the two components at a 3 : 1 ratio by volume. Stir thoroughly until a uniform consistency is achieved.
- Apply the first coat using spray or roller, maintaining proper atomization for even coverage.
- Allow the first coat to flash off for 60 minutes before applying the second coat.
- After the second coat, let the finish cure as per ambient conditions; no additional coats are required.
Specifications
| Part No. | 0821V |
|---|---|
| Product Line | UPO |
| MFR Model | UP0821V |
| Standard/Approvals | FMVSS 302 | ISO 3795 and BS AU 169A Flammability Tested | ASTM E303-93 Slip Resistance Tested | California Pro65 Warning: Cancer |
| Includes | (4) Bottles of Raptor and (1) Tin of Hardener |
| Application | Use for automotive, construction, marine, recreational, industrial, agricultural and commercial applications. |
| Manufacturer | U-POL |
| Trade Mark | RAPTOR® |
| Alternate Part Number-1 | UPO.0821VG |
| UPC | 501079610882 |
| Brand | U-POL® |
| Maximum Sale Quantity | 2 |
| Maximum Sale Day | 7 |
| Color | Tintable |
| Mixing Ratio | 3:01 |
| Coverage (sq-ft) | 125 |
| Type | 2.6 VOC |
- Mix Ratio
- 3 : 1 (resin to hardener)
- Coverage
- 125 sq-ft
- Number of Coats
- 2
- VOC
- 9.18 lb/gal US (1120 g/L)
- Flash Time
- 60 min between coats
- Compatible Substrates
- About U-POL
U-POL delivers pro-grade refinish products including Raptor bed liner, Dolphin glazes, and Power Can aerosols used in shops worldwide.
Frequently Asked Questions
What is the mix ratio for U-POL UPO?
U-POL UPO uses a mix ratio of 3:01. Always measure activators and reducers accurately to maintain film properties and pot life — deviating from the ratio can cause adhesion or curing problems.
How fast does autofxmart ship U-POL UPO?
Most in-stock orders for U-POL UPO ship the same or next business day from our US warehouse. Expedited options are available at checkout. Freight-class items may require an additional 1–2 days for carrier pickup.
Is this U-POL product genuine?
Yes. autofxmart is an authorized distributor of U-POL products. Every unit is factory-fresh, sealed, and backed by the manufacturer's standard warranty. If you have a concern, contact support@autofxmart.com and we will make it right.
What is the manufacturer part number (MPN) for U-POL UPO?
The MPN for U-POL UPO is 0821V. Use this number when cross-referencing against TDS, SDS, or legacy supplier catalogs.
Documents & Safety
Danger - Wear chemical-resistant gloves, safety goggles or face shield, protective clothing (coveralls), and a suitable respirator when handling this kit. The product is highly flammable, can cause severe skin burns and eye damage, may be harmful if inhaled as dust or mist, and is toxic to aquatic life. It also poses respiratory irritation, aspiration hazards, and carries long-term health risks such as carcinogenicity and reproductive effects. Always refer to the full SDS before use.Why Buy from autofxmart
- Authorized distributor — authentic, factory-fresh stock.
- Fast US shipping — most orders ship within 1 business day.
- 30-day returns — buy with confidence.
- Pro-shop pricing — bulk discounts available on request.
- Expert support — questions? Email us at support@autofxmart.com.
Cure & dry schedule
Timing at 77°F
Pot life
60 minutes
Flash (coats)
60 minutes
Touch dry
Less than 1 hour
Through dry
5-7 days
Bake
30 minutes @ 140°F
How to apply
Steps
1Read the product's instructions before first use.
2Set it up and check fittings/connections.
3Use steady, even technique for consistent results.
4Clean after use to keep it performing.
5Store dry and protected between jobs.
Specifications
Full data
Frequently asked
Good to know
U-POL UPO uses a mix ratio of 3:01. Always measure activators and reducers accurately to maintain film properties and pot life — deviating from the ratio can cause adhesion or curing problems.
Most in-stock orders for U-POL UPO ship the same or next business day from our US warehouse. Expedited options are available at checkout. Freight-class items may require an additional 1–2 days for carrier pickup.
Yes. autofxmart is an authorized distributor of U-POL products. Every unit is factory-fresh, sealed, and backed by the manufacturer's standard warranty. If you have a concern, contact support@autofxmart.com and we will make it right.
The MPN for U-POL UPO is 0821V. Use this number when cross-referencing against TDS, SDS, or legacy supplier catalogs.
